SAR Class CC-7 (Side B)
Class CC-7 (CCL-7, CCR-7) wagons entered service between 1984 and 1987. They are open wagons designed to transport coal and to run in drawbar coupled A-B pairs, although at present they are often made up into drawbar coupled sets of three or five. The brake wheel, shunter stirrups and handholds are on the right end of the A side, which is also always the drawbar end on wagons with a knuckle coupler on one end.

Number range 63 533 049 to 63 546 248, Length over coupling lines per wagon pair 24.140m, Length over striker castings 11.270m, Wagon spacing between striker castings 800mm, Length over pusher pads 11.094m, Length between bogie pivot centres 8.310m, Height 3.493m, Width 3.000m, Tare (average) 20,250kg, Load 84,000kg (coal) or 84,000kg (maximum), Capacity 85.66m3.
Date: 8/15/2007 Location: Vryheid, ZN,  ZA Country Flag Views: 495 Collection Of:   Col Andr√© Kritzinger
Rolling Stock: SAS 63542161 (Gondola) Author:  Andre Kritzinger
SAR Class CC-7 (Side B)
Picture Categories: RollingStock This picture is part of album:  South Africa's Rolling Stock - 60 Number Range
